Aten CS-1792 – 2-Port USB 2.0 HDMI KVMP Switch
With its unique design and innovative features, the CubiQ™ CS1792 USB 2.0 HDMI KVMP™ Switch provides both style and functionality for today's multimedia SOHO environment. Combining a 2-port switch with a 2-port USB 2.0 hub, the CS1792 provides seamless HDMI signal switching between 2 PCs or other HDMI-enabled devices, such as gaming consoles, and allows users to share USB peripherals from a single console.
The CS1792 provides enhanced independent switching via front panel pushbuttons and keyboard hotkeys, and features Video DynaSync™ technology to ensure that HDMI display resolution is always optimized. With integrated digital audio, the CS1792 also allows users to experience high-definition sound, such as Dolby True HD and DTS HD Master Audio.
Ideal for multimedia applications in the home or office, the CubiQ™ CS1792 offers the ultimate in space-saving, streamlined KVM technology for the desktop.
Specifications:
| Computer Connections | 2 | ||
| Port Selection | Front Panel Pushbuttons; Hotkeys | ||
| Connectors | Console Ports | Keyboard | 1 x USB Type A Female (Black; rear panel) |
| Video | 1 x HDMI Type A Female (Black) | ||
| Mouse | 1 x USB Type A Female (Black; rear panel) | ||
| Speaker | 2 x Mini Stereo Jack Female (Green; 1 x front, 1 x rear) | ||
| Mic. | 2 x Mini Stereo Jack Female (Pink; 1 x front, 1 x rear) | ||
| KVM Ports | Keyboard / Mouse | 2 x USB Type B Female (White) | |
| Video | 2 x HDMI Type A Female (Black) | ||
| Speaker | 2 x Mini Stereo Jack Female (Green) | ||
| Mic. | 2 x Mini Stereo Jack Female (Pink) | ||
| F/W Upgrade | 1 x 4-conductor 3.5mm Jack (Black) | ||
| Power | 1 x DC Jack | ||
| USB 2.0 Hub | 2 x USB Type A Female (White; 1 x front panel; 1 x rear panel) | ||
| Switches | Selected | 3 x Pushbutton | |
| LEDs | Audio | 3 (Green) | |
| KVM | 3 (Orange) | ||
| USB | 3 (Green) | ||
| Emulation | Keyboard/Mouse | USB | |
| Video | 1080p (HDTV) / 1920 x 1200 (DVI) | ||
| Scan Interval | 1-99 secs. (Default: 5 secs) | ||
| Power Consumption | DC 5.3 V, 3.2 W | ||
| Environment | Operating Temp. | 0-50 °C | |
| Storage Temp. | -20-60 °C | ||
| Humidity | 0-80% RH, Non-condensing | ||
| Physical Properties | Housing | Metal, Plastic | |
| Weight | 0.42 kg | ||
| Dimensions (L x W x H) | 20.50 x 7.30 x 4.50 cm | ||
Package Contents
- 1 x CS1792 USB 2.0 HDMI KVMP™ Switch
- 2 x Custom HDMI KVM Cable Sets
- 1 x Firmware Upgrade Cable
- 1 x Power Adapter
- 1 x USB-to-PS/2 Converter
- 1 x User Instructions
