Details:
The ATEN VM0404HA 4x4 4K HDMI Matrix Switch supports 4K resolutions of UHD (3840 x 2160) and DCI (4096 x 2160) with refresh rates of 30 Hz (4:4:4) and 60 Hz (4:2:0). Ready for the future of highdefinition video switching, the VM0404HA is ideal for applications where the routing of 4K digital signals is required, such as in classrooms, auditoriums, department stores and more.
The VM0404HA matrix switch offers an easy and affordable way to route any of 4 HDMI video sources to any of 4 HDMI displays and can be operated through front-panel pushbuttons, IR remote and RS-232 control, ensuring optimum viewing and control of high-definition video.
Specifications:
Video Input
- Interfaces:4 x HDMI Type A Female (Black)
- Impedance: 100 Ohm
- Max. Distance:1.8 m
Video Output
- Interfaces: 4 x HDMI Type A Female (Black)
- Impedance:100 Ohm
- Max. Distance:15 m
Video
- Max. Data Rate:10.2 Gbps (3.4 Gbps Per Lane)
- Max. Pixel Clock:340 MHz
- Compliance:
- HDMI (3D, 4K, Deep Color)
- HDCP 1.4 Compatible
- Consumer Electronics Control (CEC)
- Max. Resolution: Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
- Max. Distance:Up to 15 m
Control
- RS-232:
- Connector: 1 x DB-9 Female (Black)
- Baud rate and protocol:
- Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No, Flow Control: No
EDID Settings: EDID Mode: Default / Port1 / Remix
Power
- Connectors:1 x DC Jack (Black)
- Consumption:5 VDC, 10.58W
Environmental
- Operating Temperature:0-40°C
- Storage Temperature:-20 - 60°C
- Humidity:0 - 80% RH, Non-Condensing
Physical Properties
- Housing: Metal
- Weight: 2.02 kg ( 4.45 lb )
- Dimensions (L x W x H): 43.72 x 16.29 x 4.40 cm, (17.21 x 6.41 x 1.73 in.)
Carton Lot: 3 pcs
