- General Information
- Manufacturer
- Fortinet, Inc
- Manufacturer Website Address
- http://www.fortinet.com
- Brand Name
- Fortinet
- Product Line
- FortiSwitch
- Product Type
- Ethernet Switch
FortiSwitch Data Center switches deliver a Secure, Simple, Scalable Ethernet solution with outstanding throughput, resiliency and scalability for organizations with high performance network requirements. They are ideal for Top of Rack server or firewall aggregation applications, as well as enterprise network core or edge deployments, where high performance 10 GE or 40 GE is required. Purpose- built to meet the needs of today's bandwidth intensive data centers and enterprise networks, FortiSwitch Data Center switches deliver high-performance with a low Total Cost of Ownership.
Security Fabric Integration
Reduces complexity and decreases management cost with network security functions managed through a single console via FortiGate.
This integration allows all users to be authenticated against the same user database, regardless of whether they connect to the wired or wireless network, including temporary guest users.
In addition, same security policy can apply to a user or device regardless of how or where they connect to the network.
Designed for Data Centers
Future-proofed 10 GE to satisfy the bandwidth requirements of intensive data center and network core applications and maximizes network availability with dual power supplies.
- Interfaces/Ports
- Uplink Port
- Yes
- Modular
- Yes
- Stack Port
- Yes
- Port/Expansion Slot Details
- 48 x 10 Gigabit Ethernet Expansion Slot
- 2 x 40 Gigabit Ethernet Expansion Slot
- 4 x 100 Gigabit Ethernet Expansion Slot
- Media & Performance
- Media Type Supported
- Optical Fiber
- Ethernet Technology
- 10 Gigabit Ethernet
- 40 Gigabit Ethernet
- 100 Gigabit Ethernet
- Network Technology
- 10GBase-X
- 40GBase-X
- 100GBase-X
- I/O Expansions
- Total Number of Expansion Slots
- 54.0
- Expansion Slot Type
- SFP+
- QSFP+
- QSFP28
- Shared SFP Slot
- No
- Number of SFP+ Slots
- 48
- Network & Communication
- Layer Supported
- 3
- Management & Protocols
- Manageable
- Yes
- Power Description
- Power Source
- Power Supply
- Redundant Power Supply Supported
- Yes
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Height
- 42.9 mm
- Width
- 438.4 mm
- Depth
- 460 mm
- Weight (Approximate)
- 8.60 kg
