The Moxa EDS-510E-3GTXSFP-T is a high-performance managed industrial Ethernet switch, engineered for mission-critical applications in the harshest environments. Designed for factory automation, intelligent transportation systems (ITS), and process control, this switch guarantees operational stability with its extended temperature range of -40 to 75°C. Its robust, fanless design and IP30-rated metal housing ensure reliability and longevity, making it the perfect choice for demanding industrial network infrastructure where uptime is paramount.
Featuring a versatile port configuration with seven 10/100BaseT(X) Fast Ethernet ports and three Gigabit combo ports, the EDS-510E-3GTXSFP-T provides exceptional flexibility for your network topology. These combo ports can function as either 10/100/1000BaseT(X) Ethernet or 100/1000BaseSFP slots, allowing for high-bandwidth uplinks or the creation of a resilient Gigabit redundant ring. This adaptability ensures your network can scale and evolve without requiring a complete hardware overhaul.
Advanced network management and security are at the core of the EDS-510E-3GTXSFP-T. It supports a suite of redundancy protocols, including Moxa's Turbo Ring and Turbo Chain for ultra-fast network recovery (<20ms), alongside RSTP/STP and MSTP. Security is fortified with features like RADIUS, TACACS+, SNMPv3, HTTPS, and SSH. Furthermore, it supports key industrial protocols such as EtherNet/IP, PROFINET, and Modbus/TCP, ensuring seamless integration and monitoring within your existing industrial control systems for optimised performance and security.
Ease of use is enhanced with multiple configuration options, including a user-friendly web browser interface, a command-line interface (CLI), and a USB console port. The addition of a USB storage port simplifies firmware upgrades, configuration backups, and log file storage, significantly reducing maintenance time. With redundant power inputs and a comprehensive set of certifications, including ATEX and Class I Division 2, this switch delivers the resilience and reliability required for continuous industrial operations.
FEATURES
- Wide operating temperature range of -40 to 75°C for use in extreme conditions
- Features 7 Fast Ethernet ports and 3 Gigabit combo ports (RJ45/SFP) for flexible network design
- Supports industrial protocols including EtherNet/IP, PROFINET, and Modbus/TCP for enhanced device management
- Moxa's Turbo Ring and Turbo Chain technology provides network redundancy with <20ms recovery time
- Advanced security features including RADIUS, TACACS+, SNMPv3, HTTPS, and SSH
- Multiple configuration methods: Web browser, CLI, Telnet, and USB console
- Redundant dual 12/24/48VDC power inputs for high availability
- IP30-rated metal housing with fanless design
- Certifications for hazardous locations (Class I Div. 2, ATEX Zone 2)
SPECIFICATIONS
- RJ45 Ports: 7 x 10/100BaseT(X)
- Combo Ports: 3 x 10/100/1000BaseT(X) or 100/1000BaseSFP slots
- MAC Table Size: 8K
- Packet Buffer Size: 1Mbit
- Input Voltage: 12/24/48/-48VDC, Redundant dual inputs
- Input Current: 0.68A @ 24VDC
- Housing: Metal, IP30 protection
- Dimensions: 79.2mm x 135mm x 116mm
- Weight: 1690g
- Installation: DIN-rail mounting, Wall mounting (with optional kit)
- Operating Temperature: -40 to 75°C
- Storage Temperature: -40 to 85°C
- Ambient Relative Humidity: 5 to 95% (non-c...
